The pulp molded cup lid production line is composed of a pulping system, a host device, a vacuum system, a high-pressure water system and an air compressor system, and is used to produce disposable pulp molded cup lids. The production line uses sugarcane pulp, bamboo pulp, wood pulp, reed pulp, straw pulp and other pulp boards as raw materials, and it is prepared into a pulp with a certain concentration through the processes of hydrapulping, refining, adding chemical additives, etc. It is evenly attached to a special metal mold to form a wet blank product, and then a disposable pulp molded product is produced through the drying, hot pressing, punching and trimming, and stacking processes. The average production capacity of the host system is 100,000 pieces / day. And it can be customized per the actual situation of customers.

The feature of the host system is integrated with forming, hot pressing, punching, trimming and stacking. It is automatically and continuously completed. This greatly saves the site, labor and power consumption, and improves the start-up rate, product qualification rate and product quality and with easy maintenance.

Which is the best disposable paper cup production equipment? Recommended by European customers - BESURE Cup Lid Production Line! Located in France, Europe, BESURE automatic cup lid production line project is running at full speed, with a single-machine daily production capacity of 90,000 to attack the European cup lid market, orders are in short supply!

BESURE automatic pulp molding cup cover machine is driven by full servo motor, with fast speed and high precision, and the product qualification rate is as high as 95%. The equipment has a daily output of 100,000 pieces, and the cup lid is upside down by 50 threads. The cup lid produced by it has strong sealing performance, high buckle degree, anti-leakage, and enables a new experience in the pulp molding environmental protection industry! The production line is fully automatic and integrated, and one worker can control two machines, and the latter stage can realize automatic detection, film packaging, packing, etc., which greatly saves labor and realizes an "unmanned factory". The combination of high-precision molds and high-demand equipment is a huge research achievement of BESURE Technology.

Providing customers with integrated and optimized intelligent manufacturing solutions has become the differentiated advantage of BESURE Technology.

Model: TSMP-9570

Equipment Composition: Forming,Hot Pressing, Trimming, Stacking

Platen Size: 1000mm*750mm

Capacity Each Machine: 100,000pcs/day(basing on 80 cup lids) or 300-500kg(High-end Industrial Packaging, Capacity differs according to specific style)

Outline Dimension(mm): L 10700 * W 3290* H 3800

Forming Type: Single-sided flipping suction molding

The forming minimum shut height is 130mm(mm): 120

Hot-press standard mold closing height(mm): 220

Forming Pressure: 5T

Hot pressing pressure: 30T

Trimming Pressure: 60T

Product height(mm): ≤80

Workable Product angle (degree): ≥10

Heating Method: Electricity

Control method: PLC + touch screen

Remarks: The above parameters are for reference. Due to the continuous development of technology, relevant data will be continuously updated

High Automation

All the processes are completed automatically through the line.

Capable of producing negative angle products such as cup lids

The equipment has high positioning accuracy and cold extrusion function.

Fast speed, high precision and good controllability

The whole machine is driven by servo motor.

ABOUT BESURE

In 1997, BST team imported the European production line to China and started the business of molded pulp products production. During the past 24 years, BST team dedicate themselves to the development of pulp molding industry and continue to extend to the downstream industry.  BST has now become the group corporation of R & D, manufacture and sales of the whole pulp molding production line, mold and moleded pulp products. It' s also a China-Europe cooperative international company with foreign factories around the world and the first listed pulp molding equipment manufacturer in China.

A China-Europe cooperative company and international group.

The 1st listed company of Chinese pulp molding machine manufacturers and high-echnology company.

Focusing on pulp molding equipment for over 24 years, the leader for world high-end pulp molding equipment.

Serving more than 400 customers all over the world with 6 local service centers.

FOUCUS ON PULP MOLDING EQUIPMENT

 BeSure headquarter is located in Foshan GuangDong which is the equipment manufacturing center in China, focusing on  R&D, manufacturing and sales of various kinds of pulp molding equipment and molds. The factory covers an area of 38000 square meters and has more than 250 employees.

BeSure technical staff accounts for more than 50% of the total number of company. The current staff number for equipment R & D , engineering installation and commissioning, electrical engineering process , technical support, mold design and making, production , quality control , sales is 131 in total, including 8 doctors, 19 masters, covering multiple disciplines such as mechanical, electronic, thermal engineering, fluid mechanics, paper making, product design, engineering design etc...

The equipment workshop is divided into several parts,including cutting, welding, assembling, painting, processing, electrical assembling and so on . There are different kinds of processing equipment such as CNC machine, milling machine, drilling machine, lathe, shearing machine, bending machine, wire cutting machine, etc.

Mold manufacturing workshop includes CNC processing, drilling, mesh covering, polishing, assembly and other processes. The workshop is equipped with tableware and fine packages machine for products R & D, testing and improving. At the same time it's also used for customers visit and technician training.

There is a sample workshop for mold tesing, sampling and small quantity products production. There is an entire equipment testing system including pulping system, vacuum system, high pressure water system, compressed air system for ex factory equipment commissioning to ensure that all the equipment is qualified before shipping. In order to improve the equipment intelligence, BST set up an R&D center in Europe where the world pulp molding industry originated. There are 6 employees currently and the center is focusing on the development of automatic equipment and production line, helping on BeSure technology innovation. At present, BST has several technologies which are the first innovation in China and has several national patents, leading the world pulp molding industry development. In July 2016, BeSure and Siemens achieved the strong alliances to facilitate pulp molding production line towards intelligence.
